Accelleron Component Enhanced
TPS-F
Accelleron TPS-F compact turbochargers for small medium-speed diesel and large high-speed diesel and gas engines from 400 kW to 3,300 kW, with pressure ratios up to 5.2 and VTG versions.
Description
TPS-F turbochargers from Accelleron are compact units for small medium-speed diesel engines and large high-speed diesel and gas engines, in applications from 400 kW to 3,300 kW.
Key features
- Three radial high-pressure compressor stages covering the full range of pressure ratio and volume flow requirements
- Full-load compressor pressure ratios up to 5.2, increasing BMEP and reducing fuel consumption and emissions
- Stabilizer technology for improved stability
- High-efficiency mixed-flow turbine for strong part-load performance
- Compact design with increased power density
- Single-piece oil- or water-cooled bearing casing
- Lubricated internal plain bearings with engine-internal oil supply
- HFO-compatible turbine stage
- Choice of air intake and gas outlet arrangements; Variable Turbine Geometry (VTG) versions
- Modular design with long times between overhauls
Applications
Cruise ships and ferries, yachts and tugboats; also stationary gensets, locomotives, gas compression and off-highway vehicles.
Support
24/7 support from more than 100 service stations in over 50 countries.
