Maritime Propulsion



I was exposed to reliability engineering and conditioning monitoring through my work for the Navy contractor (Booz Allen) and later through contract work I performed with Sea Land, Exxon and AT&T cable ships. These companies saw significant benefits gained from vibration analysis, ultrasonic, thermography, and we could significantly improve machinery reliability and save a tremendous amount of labor and spare parts expense – not to mention a better performing machinery is better for the environment.



I moved to South Florida and saw there wasn’t anyone offering vibration analysis services based in Fort Lauderdale, so I started the business soon after buying a vibration analyzer in 1992. As the vibration analysis work grew, it became apparent a large percentage of vibration issues are alignment related. I expanded our services to laser alignment and field balancing so I could offer a complete solution beyond just pointing out problems. I was doing the pump work at the oil terminals and saw a lot of substandard work, with pumps failing prematurely and work which did not address the root causes of the failures. I started subcontracting pump rebuilds, et cetera to a local machine shop where I would oversee the work. I purchased that shop when it went up for sale in 2002, and it is still our main location, with our second location at Lauderdale Marine Center. Our service team travels worldwide to perform vibration, balancing and alignment services.



We have two locations in Fort Lauderdale, one of which is in Lauderdale Marine Center, the largest yacht repair facility in the world. AME has 23 employees, with mobility worldwide. We perform vibration surveys, alignment or repair work on approximately 75 to 100 vessels per year.



AME provides mechanical engineering services and products for propulsion systems, rotating and reciprocating machinery. We’re solutions-driven and focus on finding and correcting the root cause of mechanical issues to improve long term reliability and performance.



When I first established the company 25 years ago, vibration analysis was not widely accepted for machinery condition monitoring and diagnosis. Early instruments were heavy, expensive and had limited capability. Early sensors and cabling were not always reliable, causing further hesitancy by operators. Now the analyzers are much more powerful with faster processors, units are lighter and the sensors and cabling more accurate and robust. Portable handheld analyzers are now able to collect multiple channels of data, enabling more accurate analysis of a wider range of problems. The software has also improved greatly, and offers the ability to process large amount of vibration data and apply expert diagnosis to speed up the process. The future looks even more exciting as processing speeds and memory size will allow even more complex signal processing, allowing better fault diagnosis and detection. AME is committed to using the latest technologies and methods.



Most common issues for propulsion systems have to do with misalignment. Many times we find the resilient mounts are past their service life and have failed or deteriorated to the point of causing alignment problems between the engine and reduction gear. On main propulsion engines, we also pick up a lot of misfire vibration, due to a worn or bad injectors and torsional vibration due to a torsional coupling which is beyond its service life, has failed or is about to.



One of my first customers was a large, well-known cruise line. It was their flagship vessel, the first one they had built, and they had a complaint about a loud high pitch noise coming from the shaftline, following a dry docking, which they perceived as being a defective shaft bearing. I attended the vessel and was able to immediately diagnose it as a “singing” propeller. The propeller blade resonance was being excited by the vortices coming off the trailing edge of the blades. I recommended the divers grind an anti singing edge on the blades, which corrected the problem. However, while I was there, I noticed an exceptional and extreme vibration coming from the shaft generators which were driven by a pinion shaft which was integral with the propeller shafting. I came to find out that this had been an issue since the vessel was built, and resulted in catastrophic failures of the pinon shaft, rendering the shaftline inoperable and involving costly and time-consuming repairs. Vibration analysis showed a structural resonance problem of the propeller line shaft bearings. Further inspection revealed that additional structural reinforcement was needed in the double bottom to stiffen the tank top where the bearings were mounted. We were able to work together with a ship repair firm that welded in the appropriate structure while we monitored the position of the shaft bearings with precision lasers, so to maintain the shaft alignment and control the welding heat distortion. The result was a significant drop in vibration of the line shaft bearings and a happy and impressed customer.



We are in a technology intensive business, using lasers alignment systems and vibration analysis equipment and software that requires an investment in both in equipment and training. We are constantly upgrading and purchasing new equipment to better our services. It is both challenging and exciting to be on the leading edge, but there is a huge learning curve when becoming proficient in the services we provide and equipment we use. It’s not something that’s taught in the classroom. It requires a combination of knowledge, training and hands-on, real world experience.



It is rewarding as an engineer to diagnosis and solve complex vibration problems. It is also very rewarding to mentor our younger employees. Sometimes it takes perseverance, but with 25 years of business and experience behind us, we have been able to solve a lot of problems with the resources available to us and improve our customers operations and maintenance.





(As published in the November 2017 edition of Maritime Reporter & Engineering News)
